| Generelt |
| Garanti (måneder) |
18 |
| Tilstand |
Brukt |
| Status |
Testet |
| Produktnummer |
90-MXBEL0-A0UAYZ |
| Produkttype |
Hovedkort |
| EAN |
4710483933714 |
| UPC |
|
| Hovedkort |
| Prosessorsokkel |
LGA1200-sokkel |
| Brikkesett type |
Intel B560 |
| Kompatible prosessorer |
Støtter 11.- og 10.-generasjons Intel Core / Pentium Gold / Celeron |
| Støttet RAM |
| Maks størrelse |
Micro-ATX |
| Teknologi |
DDR4 SDRAM |
| Bussklokke |
2666 MHz, 4800 MHz (O.C.), 4600 MHz (O.C.), 2933 MHz |
| Støttet RAM-integritetskontroll |
Ikke-ECC |
| Registrert eller bufret |
Ikke-bufret |
| Egenskaper |
|
| Grafikk |
| Maks allokert RAM-størrelse |
128GB |
| Lyd |
| Type |
Lydkort |
| Audio Codec |
Realtek ALC897 |
| Tilpassede standarder |
High Definition Audio |
| LAN |
| Nettverkskontroller |
Intel I219V |
| Nettverksgrensesnitt |
Gigabit Ethernet |
| Ekspansjon / Tilkoplinger |
| Utvidelsesspor |
1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 4.0 x16 (dual x16, x4 mode; single card: x16 mode; PCIe 4.0 (11th Gen Intel CPUs), PCIe 3.0 (10th Gen Intel CPUs)) ¦ 1 x PCIe 3.0 x1 ¦ 1 x M.2 socket (Key E) |
| Lagergrensesnitt |
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 1 x M.2 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2 |
| RAID-funksjoner |
|
| Grensesnitt |
2 x USB 2.0 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 4 x USB 3.2 Gen 1 ¦ 1 x PS/2 keyboard / mouse ¦ 1 x HDMI ¦ 1 x LAN (Gigabit Ethernet) |
| Interne overflater |
1 x Thunderbolt - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 4 x USB 2.0 - header ¦ 1 x USB-C Gen 1 - header |
| Strømkontakter |
24-pin main power connector, 8-pin ATX12V connector |
| Egenskaper |
| BIOS Type |
AMI |
| BIOS-egenskaper |
Multilingual BIOS, UEFI BIOS, SMBIOS 2.7 support, ACPI 6.0 support |
| Sov/Våkne |
Wake on LAN (WOL) |
| Maskinvarefunksjoner |
8 Phase Power Design, ASRock Instant Flash, HDCP compliant, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, ASRock Internet Flash, Digi Power Design, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, Sapphire Black PCB, Nahimic Audio Enhacer, ASRock Live Update, ASRock EZ Mode, Premium 50A Power Choke, ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology, ASRock Steel Slots, Intel Turbo Boost Max Technology 3.0, ASRock POST Status Checker (PSC), ASRock Full Coverage M.2 Heatsink, ASRock Hyper M.2 |
| Diverse |
| Høyde |
24.4 cm |
| Bredde |
24.4 cm |
